Abacus Raised Tileable Tray Concept Kit 6 - 1850 x 750 x 40/50mm

The Concept 6 Raised Tileable Tray Kit from Abacus is designed for use where you cannot or choose not to site the drain within the floor.

The concept raised tileable shower system can be cut to size* and is suitable where longer runs are required for drainage pipework not achievable within the floor, up to 1.5m from the waste to the soil pipe. This typically will be used for high rise accommodation, hotels, commercial buildings or awkward joist locations on timber floors.

These tileable shower bases offer ultimate strength and peace of mind for customers who wish to tile their shower area.

Concept Kit 6 Features:

• Raised Shower Substructure
• Offering Max Showering Space of 1850 x 750mm
• Tileable Surface to Match Bathroom Design
• Convenient Kit Containing All You Need To Install
• Fast Flow Waste with Hair Trap

Concept Kit 6 Specs:

• Tileable Shower Tray - 750 x 900mm
• Tileable Shower Extension Board with Built-In 10mm Fall - 750 x 900mm
• Shower Tray Substrate - 750 x 900mm
• Max Height Before Tiling 50mm
• Product Code: EMKS-15-1807

Included Installation Kit Contents:

• Flexible Waterproof Tape Adhesive
• Wood Floor Primer
• Horizontal Shower Waste
• Board Fixing Adhesive
• Sealing & Mounting Adhesive
• Waterproof Joint Sealing Tape
• Waterproof Internal Corners
• Tile Guide
• Paint Brush
• Notched Trowel
• Protective Gloves

* Note: Trays can easily be reduced in length and width by cutting with a hand saw. We do not recommend cutting more than 50mm off each side of the tray when reducing width. Tray lengths can also be extended by purchasing an additional extension kit.

For more info on how to cut the tray and tray formers please refer to the manufacturer instructions prior to installation or making any cuts.
